5.18 Smart

5.18 Smart

TECHNICAL FEATURES

Stabilizers: pivoting

Lifting capacity: 4,999 kg

Capacity at maximum height: 3.000 kg

Lifting height: 17,56 m

Reach: 14,26 m

Engine: Deutz TCD 3.6 L4 - stage IV

Rated power: 100 kW - 134 cv

Number of gears: 2/2

Hydraulic system: Load Sensing 350 bar

Length: 6.69 m

Width: 2,50 m

Ground clearance: 329 mm

Empty weight: 15.630 kg

Travel speed: 40 km/h

Rotation: 360 °

Climate control as standard: Yes

Automatic accessory recognition: Yes

REGULATIONS

CE certificate

EN 1459-2: concerning standards for slewing variable-reach trucks

EN 280: concerning standards for mobile elevating work platforms

EN 13000: concerning standards for hydraulic cranes

FOPS/ROPS

UE 2016/1628: concerning engine emissions standards
