TH 6.20

TH 6.20

TECHNICAL FEATURES

Lifting capacity: 6,000 kg

Capacity at maximum height: 2,300 kg

Lifting height: 19.20 m

Reach: 14.60 m

Engine: Deutz TCD 3.6 L4 - stage IV

Rated power: 100 kW - 134 cv

Number of gears: '2/2

Hydraulic system: Load Sensing 350 bar

Length: 6.50 m

Width: 2.50 m

Ground clearance: 2,50 mm

Unladen weight: 14,500 kg

Travel speed: 40.00 Km/h

Climate control as standard: Yes

Automatic accessory recognition: Yes

REGULATIONS

CE certificate

EN 1459-2: concerning standards for slewing variable-reach trucks

EN 280: concerning standards for mobile elevating work platforms

EN 13000: concerning standards for hydraulic cranes

FOPS/ROPS

UE 2016/1628: concerning engine emissions standards
